WD-GS-24P8S4Oi Industrial PoE Switch
36-port Gigabit L3 managed switch with 10G uplinks for mission-critical networks
Industrial PoE Networking Solution
High-power PoE switching with 10G uplinks for harsh environments
WDGS-24P8S4Oi is a 36-port Gigabit L3 managed industrial PoE switch designed for extreme environments. With 24x 30W PoE+ ports, 8x Gigabit SFP slots, and 4x 10G SFP+ uplinks, it delivers 128Gbps non-blocking switching for bandwidth-intensive applications. Its IP40-rated metal housing and -40°C to 85°C operating range ensure reliability in harsh conditions. Advanced features include AI-powered PoE management (auto-reboot, scheduling), <10ms failover via RUN-Ring technology, and Layer 3 routing (OSPF/RIP for IPv4/IPv6). Ideal for video surveillance, transportation networks, and outdoor deployments where power and connectivity must be maintained under extreme conditions.
Solution Key Benefits
Experience the difference our powerful features make — built for businesses that demand performance, protection, and growth at scale.
High-Density PoE+
24x 30W PoE+ ports (802.3at/af) with AI power management
Industrial Tough
IP40 metal housing, -40°C to 85°C operation, 6KV surge protection
10G Uplinks
4x 10G SFP+ ports for high-bandwidth backbone connectivity
Ultra-Fast Redundancy
<10ms failover with RUN-Ring (ERPS) technology
Layer 3 Routing
IPv4/IPv6 support (OSPF, RIP, static routing)
AI Surveillance Ready
IGMP snooping and QoS for multi-camera deployments
Key Features
- 1. Rugged Design: -40°C to 85°C operating temperature with IP40-rated metal enclosure
- 2. High-Density PoE: 24x Gigabit PoE+ ports (30W/port, 36W max) with AI power management
- 3. Advanced Redundancy: RUN-Ring technology for <10ms failover (ERPS compliant)
- 4. Layer 3 Routing: Supports IPv4/IPv6 static/dynamic routing (RIP, OSPF, RIPng, OSPFv3)
- 5. Security: 6KV lightning protection, 802.1X, MAC/IP/port binding, and ACLs
Power Over Ethernet for Harsh Environments
WD-GS-24P8S4Oi delivers PoE+ and 10G connectivity where AC power is unavailable
